【Model】BVS-GW-A
【Item】Mini PC Dual LAN Micro Industrial Computer
【Notice】
- Please contact us if you need other specifications.
- Payment terms: Samples 100% payment in advance, bulk order 30% deposit, 70% payment before shipment. Sample order accepted.
- Sample delivery time is 7 working days after payment is received for bulk orders, and shipping time is negotiated.
- The shipping fees should be covered by buyers, please contact us for details.
- Warranty: One year.
【Paramater List】
|
Model |
BVS-GW-B |
|
|
Case
|
Material/Structure |
All aluminum alloy without fan |
|
Color |
Black |
|
|
Dimensions (length, width, height) |
135 * 125 * 40 mm |
|
|
Weight (bare metal net weight) |
1.06KG |
|
|
Motherboard
|
CPU |
Intel ® Celeron ® Processor J1900 |
|
Display |
Integrated Intel® Iris™ Graphics supports DirectX 11.1 OpenGL 3.2 |
|
|
RAM |
DDR3L 2G (optional 4G/8G) |
|
|
Front panel interface
|
POWER |
1* Power Switch |
|
USB |
4* USB3.0 Interfaces |
|
|
COM |
2* DB9 serial interface, COM5, COM6 support RS232/RS485 switch |
|
|
Audio |
1* Audio Interface |
|
|
Rear panel interface
|
Display interface |
1*VGA interface, 1*HDMI 1.4 interface |
|
LAN |
2*Intel® WGI211AT Gigabit network card, support Wake on LAN, PXE function |
|
|
USB |
2* USB2.0 interface |
|
|
power supply |
1* DC power adapter interface, supports DC12V power input |
|
|
storage
|
SANTA |
1*2.5 inch hard drive expansion |
|
Solid state drive |
1* MSATA SSD solid state drive expansion, transmission speed up to 6Gbps |
|
|
software support
|
Microsoft Windows |
Windows 7 (default)/Windows 10 |
|
Linux |
hardware only, system not included |
|
|
Power requirement
|
Power type |
External power adapter |
|
Voltage input |
DC 12V |
|
|
Power output |
AC TO DC, 36W / 60W (optional) |
|
|
surroundings |
Operating temperature |
-10℃～60℃ |
|
storage temperature |
-20℃～70℃ |
|
|
Relative humidity |
5%-95% relative humidity, non-condensing |
|
|
Job vibration |
0.5g rms/5-500HZ/random/operating |
|
【Features】
a) 1 * HDMI, supporting 4K display
b) Full function (date/charge/audio)
c) 4 * USB 3.0, supports quick charge
d) Rich interface, full functions
e) Smart meeting + Office business
【About Package】
One piece per box.
【Application】
Digital signage, smart home, smart conference, educational use or home theater, etc.
